Frisian Cruiser 9.30 OK AK

General

• Remarks:

  Very well maintained Frisian Cruiser, by the yard with solid teak ingetimmerd yacht. Spacious open cockpit with wide bench and outside cushions. You can sail this ship under many bridges because of the low vertical clearance of 2.45 / 1.85 meters. Spacious salon with round seat, which can be converted into a double bed with lots of storage space. Galley with hood. Combined shower/toilet area with sink and storage cabinet. Double bed in the master cabin. Bow thruster and cockpit tent available!


  Click here for more information


• Shipyard: RFU Jachtspecialist Jirnsum
• CE-category: C
• Hull shape: Chine
• Hull colour: White
• Deck colour: White
• Deck construction: Steel
• Windows: Aluminium windows, single glazed, light tinted
• Cockpit: Centre cockpit
• Open cockpit:
• Aft cockpit:
• Vertical clearance: 2.45 m
  with mast 3.25 m (1.85 m with folded wind screens!)
• Minimum height: 185 cm
• Draught: 90 cm
• Displacement: 8,000 kg
• Steering system: Wheel
• Position steering system: Outside
• Rudder: Single
• Comments:

  Technical Specifications

  • Name: Swalker
  • Brand: Frisian
  • Type: Cruiser 9.30 OK AK
  • Year built: 2006, refit 2022
  • Mooring: Harderwijk
  • Shipyard: RFU Jachtspecialist Jirnsum
  • Weight appr. 8.000 kG
  • Length: 9.30 m
  • Width: 3.30 m
  • Draught: 0.90 m
  • Headroom: 2.45 m, with mast 3.25 m (1.85 m with folded windscreens!)
  • Hull shape: knuckle bilge
  • Hull: steel
  • Superstructure: steel
  • Decks and gangways: steel
  • Maximum speed: approx. 16 km/hour
  • Engine: Nanni (Kubota) 4 220 HE diesel, 4 cylinder, 55 HP
  • Running hours: ca. 1500
  • Gearbox hydraulic, ZF
  • Direct shaft coupling: Python
  • Hydraulic steering
  • Wet exhaust
  • Water lubricated propeller shaft
  • 4-blade propeller
  • Stainless steel exhaust
  • Bow thruster electric Vetus 12V
  • Aluminum windows, single glazed, slightly tinted
  • Fuel tanks: 2 x 350 liters steel
  • Water tank: 300 liters stainless steel
  • Holding tank (black): 100 liters stainless steel
  • Holding tank (grey): 100 liters stainless steel
  • Cabins: 1
  • Berths: 2 + 2
  • Carpentry: solid teak, floors with teak and ash trim also in cockpit
  • Yacht is registered in the land registry

  Electrical installation

  • 12/230V
  • Shore power
  • Shore power cable
  • Battery charger: Victron Ivo Smart 50A
  • Light batteries: 2 x 130 Ah
  • Bow thruster battery: 130 Ah
  • Starter battery: 130 Ah
  • Inverter: Mastervolt 1500W
  • Battery monitor: Victron BMV-700
  • Alternator 100A
  • Solar panels portable with Solar 30 controller

  Equipment dashboard

  • Hour counter
  • Temperature gauge
  • Oil pressure gauge (acoustic alarm at steering position)
  • Voltmeter
  • Depth sounder: Raymarine
  • Navigation lights
  • Horn
  • 2 windscreen wipers
  • Teak windshields, folding

  Kitchen equipment

  • 4-burner stainless steel gas stove
  • Sink and faucet
  • Refrigerator: 80 liters: Coolmatic/ Waeco RPD-0080E with freezer compartment and compressor
  • Cooker hood

  Wet cells

  • Electric toilet with storage cabinet and design glass sink
  • Shower with shower cabin and thermostatic faucet

  Exterior equipment

  • Covered open cockpit
  • Stainless steel stairs
  • Stainless steel folding bathing ladder
  • Teak mast, stainless steel mast foot and folding option
  • Stainless steel bollards
  • Stainless steel hand rail, around the cockpit with teak top rail
  • Manually operated anchor winch
  • Stainless steel anchor
  • Fenders 6
  • Mooring ropes
  • Cockpit tent blue
  • Anti-slip on front, aft deck and gangways

  Accessories/ extras

  • Heating: Webasto, diesel hot air
  • Hydrophore and water pump
  • 50 liter boiler
  • Large yard in foredeck
  • Escape hatch
  • Steering seat
  • 2 Fire extinguishers and automatic fire extinguishing system in engine room
  • Insulation
  • Coffee table
  • CE: C
  • Blue fabric upholstery
  • Anti-fouling from 2022
  • Bilge pump
  • Stainless steel rubbing strip, also on rubbing strakes
  • Folding stairs in cockpit

  Dimensions

  • Headroom saloon: 195 cm
  • Headroom master cabin: 195/120 cm
  • Headroom wet room: 195 cm
  • Bed in master cabin: 140 x 200 cm with slatted frame
  • Bed on round seat: 190 x 200 cm

  Layout

  Spacious cockpit with steering position, saloon with on starboard side the galley and on port side the combined shower/toilet. Front round seat, which can be converted into a double bed. Double bed in the aft cabin. Wide gangways all around and fixed swimming platform accessible via stainless steel stairs. Open cockpit with fixed bench seat that also provides access to the aft cabin (rotating). Folding cockpit table.

  Disclaimer

  The specifications are provided by the owner and / or manufacturer, no rights can be derived.

  The specifications are provided by the owner and/ or manufacturer, no rights can be derived from this.

  Die Angaben beziehen sich auf Eigentümer und/ oder Hersteller, hieraus können keine Rechte abgeleitet werden.

Accommodation

• Saloon:
• Headroom: 195 cm
• Separate Dining area:
• Cabins: 1
• Berths: fixed: 2 Extra: 2
• Type interior: Classic, warm
• Color upholstery: Blue
• Mattresses:
• Cushions:
• Curtains:
• Water tank & material: 300 litre Stainless steel
• Water tank gauge:
• Waste water tank: 200 Litre Stainless steel
  Holding tank (black): 100 liters stainless steel Holding tank (gray): 100 liters stainless steel
• Waste water tank gauge:
• Waste water tank drainpump:
• Deck suction:
• Water system: Pressure system
  Hydrophore and water pump
• Hot water: Boiler 50 litres
• Number of showers: 1
• Toilets: 1 Electric
• Cooker & fuel: 4 burner(s) Gas
  STAINLESS STEEL
• Fridge & power source: 80 Litre Electric
  Coolmatic/Waeco RPD-0080E with freezer compartment and compressor
• Heating: hot air
  Webasto, hot air on diesel

Engine, electrics

• Number of identical engines: 1
• Starting type: Electric
• Type: Inboard
• Brand: Nanni (Kubota)
• Model: 4 220 HE diesel
• Year: 2006
• Number of cylinders: 4
• Power: 55 hp
• Hours counter:
• Engine hours: 1,500
• Fuel: Diesel
• Fuel consumption: 2 litre/hour
• Gearbox: hydraulisch, ZF
• Transmission: Shaft
• Propulsion: Propellor
• Cooling system: Indirect
• Fuel tanks: 2
• Total fuel tank(s) capacity: 700 Litre
• Fuel tank material: Steel
• Max speed: 16 km/h
• Cruising speed: 10 km/h
• Fuel tank gauge:
• Tachometer:
• Oil pressure gauge:
• Temperature gauge:
• Bow thruster: Electric
  Vetus 12V
• Battery: 4 x 130 Ah
  Light batteries: 2 x 130 Ah,Bow thruster battery: 130 Ah, Starter battery: 130 Ah
• Battery charger: 50 A
  Victron Ivo Smart 50A
• Alternator: 100 A
• Battery monitor:
• Inverter: 1.500 Watt
  Mastervolt 1500W
• Voltmeter:
• Shore power:
• Shore power cable:
• Voltage: 12V 220V

Navigation and electronics

• Depth gauge: Raymarine
• Navigation lights:

Rig and sails

• Number of masts: 1
  Teak mast, stainless steel mast foot and with folding facility
• Spars material: Wood

Deck Equipment

• Anchors & material: 1 x Stainless steel
• Anchor connection: Chain
• Anchor windlass: Manual
• Cockpit tent:
• Outdoor cushions:
• Sea rails: Stainless steel hand rail, round cockpit with teak top rail
• Swimming ladder: STAINLESS STEEL
• Fenders, lines:

Safety

• Bilge pump: Electric
• Fire extinguisher:
• Gas bottle locker with drain:

This boat data may have been translated into your language via an automatic translation program. Errors can occur during this process. Ask the seller for complete boat details before purchasing.
